Stainless Steel 1.5 Years 0.01mm Spur Bevel Gear

Large Image : Stainless Steel 1.5 Years 0.01mm Spur Bevel Gear

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	MW
Model Number:	M1 M1.5 M2 M2.5 M3 M4 M5

Payment & Shipping Terms:

Minimum Order Quantity:	100PCS
Price:	USD1-20/PCS
Packaging Details:	STANDARD SEA WORTHY PACKAGE
Delivery Time:	20-40DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	5000000PCS/MONTH

Contact Now

Detailed Product Description

Shape:	Bevel	Warranty:	1.5 Years
Material:	Steel	Processing:	CNC Machining
OEM:	Support	Tolerance:	0.01-0.05mm Or Customized
High Light:	steel Gears , pinion gear

OEM Plastic Aluminum Brass Cast Iron Stainless Steel Metal Spur Gear With High Precision

Our helical gear,spur gear,transmission gear,bevel gear can be standard as per European or American standard or special as per

customer's drawing or sample.

Our gear quality is high and it is exported to Europe and America in big quantity

Our gear can be standard as per European or American standard or special as per your drawing or sample. Many of our European or

American customer ask us to produce as per their drawing based on OEM to meet their request

The material can be carbon steel such as C45, 20CrMnTi, 40Cr, 42CrMo and so on or stainless steel or copper or nylon and so on

If you need high precision on teeth of gear, we can meet your request too

Our products are exported to Europe and America in big quantity and so we are sure that we can help you to win great success!

Material	Carbon Steel	SAE1020, SAE1045, Cr12, 40Cr, Y15Pb, 1214Letc
	Alloy Steel	20CrMnTi, 16MnCr5, 20CrMnMo, 41CrMo, 17CrNiMo5etc
	Brass/Bronze	HPb59-1, H70, CuZn39Pb2, CuZn40Pb2, C38000, CuZn40etc
Tolerance Control	Outer Diameter	Based on drawing
	Length Dimension	Based on drawing
Machining Process	Gear Hobbing, Gear Milling, Gear Shaping, Gear Broaching, Gear Shaving, Gear Grinding and Gear Lapping
Teeth Accuracy	DIN Class 4, ISO/GB Class 4, AGMA Class 13, JIS Class 0
Modules	1.0, 1.25, 1.5, 1.75, 2.0, 2.25, 2.5....8.0 etc
Heat Treatment	Quenching & Tempering, Carburizing & Quenching, High-frequency Hardening, Carbonitriding
Surface Treatment	Blacking, Polishing, Anodization, Chrome Plating, Zinc Plating, Nickel Plating
Standard	1. DIN, ISO/GB, AGMA, JIS,ISO/TS16949:2009

Stainless Steel 1.5 Years 0.01mm Spur Bevel Gear

Z	Mod.1				Mod. 1.5
Z	de	dp	dm	D1	de	dp	dm	D1
12	14	12	9	6	21	18	14	8
13	15	13	10	6	22.5	19.5	15	8
14	16	14	11	6	24	21	17	8
15	17	15	12	6	25.5	22.5	18	8
16	18	16	13	6	27	24	19	8

17	19	17	14	6	28.5	25.5	20	8
18	20	18	15	8	30.2	27	20	8
19	21	19	15	8	31.5	28.5	20	8
20	22	20	16	8	33	30	25	8
21	23	21	16	8	34.5	31.5	25	10

22	24	22	16	8	36	33	25	10
23	25	23	18	8	37.5	34.5	25	10
24	26	24	20	10	39	36	25	10
25	27	25	20	10	40.5	37.5	25	10

26	28	26	20	10	42	39	30	12
27	29	27	20	10	43.5	40.5	30	12
28	30	28	20	10	45	42	30	12
29	31	29	20	10	46.5	43.5	30	12
30	32	30	20	10	48	45	30	12
31	33	31	25	10	49.5	46.5	35	12

32	34	32	25	10	51	48	35	12
33	35	33	25	10	52.5	49.5	35	12
34	36	34	25	10	54	51	35	12
35	37	35	25	10	55.5	52.5	35	12
36	38	36	25	10	57	54	35	12

37	39	37	25	10	58.5	55.5	40	12
38	40	38	25	10	60	57	40	12
39	41	39	25	10	61.5	58.5	40	12
40	42	40	25	10	63	60	40	12
41	43	41	30	10	64.5	61.5	40	12

42	44	42	30	10	66	63	50	12
43	45	43	30	10	67.5	64	50	12
44	46	44	30	10	69	66	50	12
45	47	45	30	10	70.5	67.5	50	12
46	48	46	30	10	72	69	50	14

47	49	47	30	10	73.5	70.5	50	14
48	50	48	30	10	75	72	50	14
49	51	49	30	10	76.5	73.5	50	14
50	52	50	30	12	78	75	50	14
51	53	51	40	12	79.5	76.5	60	14

52	54	52	40	12	81	78	60	14
53	55	53	40	12	82.5	79.5	60	14
54	56	54	40	12	84	81	60	14
55	57	55	40	12	85.5	82.5	60	14
56	58	56	40	12	87	84	60	16

57	59	57	40	12	88.5	85.5	60	16
58	60	58	40	12	90	87	60	16
59	61	59	40	12	91.5	88.5	60	16
60	62	60	40	12	93	90	60	16
61	63	61	50	12	94.5	91.5	70	16

62	64	62	50	12	96	93	70	16
63	65	63	50	12	97.5	94.5	70	16
64	66	64	50	12	99	96	70	16
65	67	65	50	12	100.5	97.5	70	16
66	68	66	50	12	102	99	70	16

67	69	67	50	12	103.5	100.5	70	16
68	70	68	50	12	105	102	70	16
69	71	69	50	12	106.5	103.5	70	16
70	72	70	50	12	108	105	70	16
72	74	72		12	111	108		16

75	77	75		12	115.5	112.5		16
76	78	76		12	117	114		16
80	92	80		12	123	120		16
85	87	85		12	130.5	127.5		16
90	92	90		12	138	135		16

Z	Mod.2				Mod.2.5
Z	de	dp	dm	D1	de	dp	dm	D1
12	28	24	18	10	35	30	22	10
13	30	26	20	10	37.5	32.5	25	10
14	32	28	22	10	40	35	28	10
15	34	30	24	10	42.5	37.5	30	10
16	36	32	25	10	45	40	32	12

17	38	34	25	10	47.5	42.5	35	12
18	40	36	25	10	50	45	35	12
19	42	38	25	10	52.5	47.5	35	12
20	44	40	30	10	55	50	40	12
21	46	42	30	12	57.5	52.5	40	14

22	48	44	30	12	60	55	45	14
23	50	46	30	12	62.5	57.5	45	14
24	52	48	35	12	65	60	45	14
25	54	50	35	12	67.5	62.5	50	14

26	56	52	40	12	70	65	50	14
27	58	54	40	12	72.5	67.5	50	14
28	60	56	40	12	75	70	50	14
29	62	58	40	14	77.5	72.5	50	14
30	64	60	40	14	80	75	55	14
31	66	62	45	14	82.5	77.5	55	16

32	68	64	45	14	85	80	55	16
33	70	66	45	14	87.5	82.5	55	16
34	72	68	45	14	90	85	55	16
35	74	70	45	14	92.5	87.5	60	16
36	76	72	45	14	95	90	60	16

37	78	74	50	14	97.5	92.5	60	16
38	80	76	50	14	100	95	60	16
39	82	78	50	14	102.5	97.5	60	16
40	84	80	50	14	105	100	70	16
41	86	82	55	16	107.5	102.5	70	16

42	88	84	55	16	110	105	70	16
43	90	86	55	16	112.5	107.5	70	16
44	92	88	60	16	115	110	70	16
45	94	90	60	16	117.5	112.5	70	16
46	96	92	60	16	120	115	70	20

47	98	94	70	16	122.5	117.5	80	20
48	100	96	70	16	125	120	80	20
49	102	98	70	16	127.5	122.5	80	20
50	104	100	70	16	130	125	80	20
51	106	102	70	16	132.5	127.5	80	20

52	108	104	70	16	135	130	90	20
53	110	106	70	16	137.5	132.5	90	20
54	112	108	70	16	140	135	90	20
55	114	110	70	16	142.5	137.5	90	20
56	116	112	70	16	145	140	100	20

57	118	114	70	16	147.5	142.5	100	20
58	120	116	70	16	150	145	100	20
59	122	118	70	16	152.5	147.5	100	20
60	124	120	70	16	155	150	100	20
61	126	122	80	16

62	128	124	80	16
63	130	126	80	16
64	132	128	80	16
65	134	130	80	16	167.5	162.5		20
66	136	132	80	16

67	138	134	80	16
68	140	136	80	16
69	142	138	80	16
70	144	140	80	16	180	175		20
72	148	144		16	185	180		20

75	154	150		20	192.5	187.5		20
76	156	152		20	195	190		20
80	164	160		20	205	200		25
85	174	170		20	217.5	212.5		25
90	184	180		20	230	225		25

Stainless Steel 1.5 Years 0.01mm Spur Bevel Gear

Z	Mod.3				Mod.4
Z	de	dp	dm	D1	de	dp	dm	D1
12	42	36	27	12	56	48	35	14
13	45	39	30	12	60	52	40	14
14	48	42	33	12	64	56	45	14
15	51	45	35	12	68	60	45	14
16	54	48	38	14	72	64	50	16

17	57	51	42	14	76	68	50	16
18	60	54	45	14	80	72	50	16
19	63	57	45	14	84	76	60	16
20	66	60	45	14	88	80	60	16
21	69	63	45	16	92	84	70	16

22	72	66	50	16	96	88	70	16
23	75	69	50	16	100	92	75	20
24	78	72	50	16	104	96	75	20
25	81	75	60	16	108	100	75	20
26	84	78	60	16	112	104	75	20

27	87	81	60	16	116	108	75	20
28	90	84	60	16	120	112	75	20
29	93	87	60	16	124	116	75	20
30	96	90	60	16	128	120	75	20
31	99	93	60	16	132	124	80	20

32	102	96	70	16	136	128	80	20
33	105	99	70	16	140	132	80	20
34	108	102	70	16	144	136	80	20
35	111	105	70	16	148	140	80	20
36	114	108	70	20	152	144	80	25

37	117	111	70	20
38	120	114	80	20	160	152		25
39	123	117	80	20				25
40	126	120	80	20	168	160
41	129	138	90	20

42	132	126	80	20
43	135	129	80	20
44	138	132	90	20
45	141	135	90	20	188	180		25
46	144	138	90	20

47	147	141	100	20
48	150	144	100	20	200	192		25
50	156	150		20	208	200		25
52	162	156		20	216	208		25
55	171	165		20	228	220		25

57	177	171		20	236	228		25
60	186	180		20	248	240		25
65	201	195		20	268	260		25
70	216	210		25	288	280		25
72	222	216		25

75	231	225		25	308	300		25
76	234	228		25	312	304		30
80	246	240		25	328	320		30
85	261	255		25	348	340		30
90	276	270		25	368	360		30

95	291	285		25	388	380		30
100	306	300		25	408	400		30
110	336	330		25	448	440		30
114	348	342		30	464	456		30
120	366	360		30

127	387	381		30

Z	Mod.5				Mod.6
Z	de	dp	dm	D1	de	dp	dm	D1
12	70	60	45	20	84	72	54	20
13	75	65	50	20	90	78	60	20
14	80	70	55	20
15	85	75	60	20	102	90	70	20
16	90	80	65	20	108	96	75	20

17	95	85	70	20
18	100	90	70	20	120	108	80	20
19	105	95	70	20
20	110	100	80	20	132	120	90	20
21	115	105	80	20

22	120	110	80	20
23	125	115	90	20
24	130	120	90	20	156	144	110	25
25	135	125	90	20	162	150	110	25
26	140	130	100	20

27	145	135	100	20
28	150	140	100	25	180	168		25
29	155	145	110	25
30	160	150	110	25	192	180		25
31

32	170	160		25	204	192		25
33
34
35	185	175		25	222	210		25
36

37	200	195		25	240	220		25
38
39	210	200		25	252	240		25
40
41

42
43
44
45	235	225		25
46

47
48	200	192		25	250	240		25
50	208	200		25	260	250		30
52	216	208		25	270	260		30
55	228	220		25	285	275		30

57	236	228		25	295	285		30
60	248	240			310	300		30
65	268	260		25	335	325		30
70	288	280		25	360	350		30
72				25

75	308	300			385	375		30
76	312	304		25	390	380		30
80	328	320		30	410	400		30
85	348	340		30	435	425		30
90	368	360		30	460	450		30
				30
95	388	380			485	475		30
100	408	400		30	510	500		30
110	448	440		30	560	550		30
114	464	456		30	580	570		30
120				30

127

Stainless Steel 1.5 Years 0.01mm Spur Bevel Gear

Hangzhou Ocean Industry Co., Ltd. is a specialized supplier of a full range of chains, sprockets, gears, gear racks, v belt pulley, timing pulley, V-belts, couplings, machined parts and so on.

Due to our sincerity in offering best service to our clients, understanding of your needs and overriding sense of responsibility toward filling ordering requirements, we have obtained the trust of buyers worldwide. Having accumulated precious experience in cooperating with foreign customers, our products are selling well in the American, European, South American and Asian markets. Our products are manufactured by modern computerized machinery and equipment. Meanwhile, our products are manufactured according to high quality standards, and complying with the international advanced standard criteria.

With many years' experience in this line, we will be trusted by our advantages in competitive price, one-time delivery, prompt response, on-hand engineering support and good after-sales services.

Additionally, all our production procedures are in compliance with ISO9001 standards. We also can design and make non-standard products to meet customers' special requirements. Quality and credit are the bases that make a corporation alive. We will provide best services and high quality products with all sincerity. If you need any information or samples, please contact us and you will have our soon reply.

FAQ:

Q1: Are you trading company or manufacturer ?

A: We are factory.

Q2: How long is your delivery time and shipment?

1.Sample Lead-times: generally 10 workdays.

2.Production Lead-times: 20-40 workdays after getting your deposit.

Q3. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery.

Q4: What is your advantages?

1. Manufacturer,the most competitive price and good quality.

2. Perfect technical engineers give you the best support.

3. OEM is available.

4. Rich stock and quick delivery.

Q5. If you can’t find the product on our website,what do you next?

Please send us inquiry with product pictures and drawings by email or other ways and we'll check.
