6 Mm Keyway Size Grid Spring Coupling Providing Shaft Misalignment 0.2 Degrees Engineered for Long Lasting and Operation

Product Description:

The Rigid Couplings product is a highly reliable and durable component specifically designed for use in industrial machinery. Weighing in at a sturdy 0.5 Kg, this coupling is engineered to provide a strong and secure connection between rotating shafts, ensuring minimal misalignment and efficient power transmission. Its bore diameter of 25 mm makes it suitable for a wide range of applications where precise shaft alignment is critical.

This particular model is a Flanged type, which means it features a flange connection that allows for easy installation and maintenance. The flange rigid coupling design is especially advantageous in industrial settings because it provides a robust and rigid link between shafts, reducing the chance of slippage and enhancing overall system stability. The flange also facilitates the assembly and disassembly process, making it ideal for machinery that requires frequent maintenance or part replacement.

One of the key features of this Rigid Couplings product is its surface treatment. It is zinc plated, providing excellent corrosion resistance and extending the lifespan of the coupling even in harsh industrial environments. The zinc plating not only protects the coupling from rust and wear but also gives it a smooth finish that reduces friction and wear between connected components.

In terms of application, this flange rigid coupling is widely used in various types of industrial machinery, including pumps, compressors, conveyors, and other mechanical systems that demand precise and reliable shaft connections. Its robust construction and high-quality surface treatment make it suitable for heavy-duty use where consistent performance and durability are essential.

Additionally, the product can serve as an effective casing coupling, providing a rigid and secure connection between the casing parts of machinery. This ensures that the casing remains aligned and stable during operation, which is vital for maintaining the integrity and efficiency of the equipment. The casing coupling function further highlights the versatility and comprehensive utility of this rigid coupling in industrial applications.

For specialized electronic applications, this Rigid Couplings product complements Flex Rigid PCB designs where mechanical stability and precise alignment are necessary. While Flex Rigid PCBs are known for their flexibility and compactness in electronic assemblies, the inclusion of flange rigid couplings in associated mechanical components ensures that the entire system operates smoothly without mechanical failures due to misalignment or vibration.

Overall, the Rigid Couplings product with its 0.5 Kg weight, 25 mm bore diameter, flanged type design, and zinc-plated surface treatment is an essential component for industrial machinery requiring dependable and long-lasting shaft connections. Its ability to function effectively as a flange rigid coupling, casing coupling, and its compatibility with systems involving flex rigid PCB technology underscores its versatility and high performance in demanding industrial environments.

Choosing this Rigid Couplings product means investing in a component that delivers strength, reliability, and corrosion resistance, ensuring that your machinery operates efficiently and with minimal downtime. Whether it is used in heavy industrial equipment or precision electronic assemblies, it provides a secure and durable connection that helps maintain optimal performance and extends the service life of your machinery.

Features:

• Product Name: Rigid Couplings
• Weight: 0.5 Kg
• Connection Type: Bolted
• Type: Flanged
• Application: Industrial Machinery
• Size: 1 Inch
• Designed for secure and precise connection, unlike Ball Joint Coupling which allows movement
• Provides a solid connection, contrasting with Flexible Jaw Coupling that offers flexibility
• Ideal for applications requiring rigidity, unlike Flexible Rubber Coupling which absorbs vibration

Technical Parameters:

Applications:

The MW brand Rigid Couplings, manufactured in China, are engineered to provide reliable and robust connections in various mechanical and industrial applications. These flanged rigid couplings, made from high-quality steel, weigh approximately 0.5 kg and are designed to handle a torque capacity of up to 1000 Nm. Their temperature range of 0-100 degrees Celsius ensures stable performance under typical operating conditions, making them suitable for a wide range of environments.

Rigid couplings like the MW Flange Rigid Coupling are ideal for applications that require precise shaft alignment and minimal backlash. They are commonly used in heavy machinery, automotive drives, pumps, compressors, and conveyor systems where maintaining a solid connection between shafts is critical. The flanged design facilitates easy installation and maintenance, providing a secure and sturdy joint that withstands high torque loads without slipping or deformation.

In hydraulic systems, the MW Flat Face Hydraulic Coupling plays a vital role by ensuring leak-free connections between hydraulic components. Its flat face design helps in minimizing contamination and fluid loss, which is essential in maintaining system efficiency and safety. These couplings are often employed in construction equipment, agricultural machinery, and industrial hydraulic circuits where durability and reliability are paramount.

While rigid couplings offer firm connections, some applications may benefit from the use of Flexible Diaphragm Couplings, which accommodate slight misalignments and reduce vibration. However, when shaft alignment is precise and rigidity is required, MW’s Flanged Rigid Couplings provide an excellent solution. Their steel construction and robust torque capacity make them suitable for environments where high mechanical stress and temperature variations occur.

Overall, MW’s range of rigid couplings, including the Flat Face Hydraulic Coupling and Flange Rigid Coupling, serve diverse industrial needs. From manufacturing plants and automotive assembly lines to heavy-duty hydraulic applications, these couplings ensure reliable power transmission and operational stability. Their ability to maintain performance within a temperature range of 0-100 degrees Celsius further broadens their applicability across multiple industries.

Customization:

MW offers customizable rigid couplings designed to meet the specific needs of various industrial machinery applications. Manufactured in China from high-quality steel, these rigid couplings ensure durability and reliable performance within a temperature range of 0-100 degrees Celsius. With a bore diameter of 25 mm and a keyway size of 6 mm, our rigid couplings are precisely engineered for optimal fit and function.

Our product customization services include options for Bellows Shaft Coupling and Casing Coupling configurations, allowing you to select the ideal coupling type based on your operational requirements. Additionally, we provide Agricultural Quick Couplings tailored for efficient and secure connections in agricultural machinery.

Choose MW's rigid couplings for robust and adaptable solutions that enhance machinery performance across diverse industrial and agricultural applications.

Support and Services:

Our Rigid Couplings are designed to provide a secure and precise connection between shafts in mechanical systems. For technical support, please refer to the product manual for installation guidelines, torque specifications, and maintenance instructions to ensure optimal performance and longevity.

If you encounter any issues or require assistance with product selection, installation, or troubleshooting, our technical support team is available to help. We recommend providing detailed information about your application, including shaft sizes, torque requirements, and operating conditions, to receive the most accurate guidance.

We also offer custom engineering services to tailor rigid couplings to your specific needs. For service inquiries, please have your product model and serial number ready to facilitate prompt assistance.

Regular inspection and maintenance of the rigid couplings are essential to prevent wear and ensure reliable operation. Replace any damaged or worn components immediately to avoid system downtime.

For detailed technical documentation, CAD files, and compatibility charts, please visit our official website or product resource center.

Packing and Shipping:

Our rigid couplings are carefully packaged to ensure maximum protection during transit. Each coupling is individually wrapped in protective material to prevent scratches and damage. The products are then placed in sturdy, corrugated cardboard boxes designed to withstand shipping stresses.

For bulk orders, couplings are securely stacked with adequate padding and separators to avoid movement and impact. All packages are clearly labeled with product details and handling instructions to facilitate smooth processing and delivery.

We partner with reliable shipping carriers to guarantee timely and safe delivery to your specified location. Tracking information is provided for every shipment, allowing you to monitor your order until it arrives.

FAQ:

Q1: What is a rigid coupling?

A1: A rigid coupling is a mechanical device used to connect two shafts together to transmit torque without any relative motion between them. It ensures precise alignment and minimal backlash.

Q2: What brand manufactures this rigid coupling?

A2: This rigid coupling is manufactured by the brand MW.

Q3: Where is the MW rigid coupling made?

A3: The MW rigid coupling is made in China.

Q4: Can the MW rigid coupling accommodate misalignment between shafts?

A4: No, rigid couplings are designed for applications where shafts are perfectly aligned. They do not accommodate angular, parallel, or axial misalignment.

Q5: Is there a specific model number for the MW rigid coupling?

A5: This product does not have a specific model number; it is identified by the brand MW and its type as a rigid coupling.
